Smart Machine Smart Decision

SIM7500_SIM7600 Series_AT Command Manual_V1.07 2017-12-25

368

AT+CNETSTOP

+CNETSTOP: 0

16.3 AT+CNETIPADDR Inquire PDP address

Description

This command inquires the IP address of current active PDP.

SIM PIN References

YES

Vendor

Syntax

Read Command

Responses

AT+

CNETIPADDR?

+CNETIPADDR: < ip_address>

+CNETIPADDR: <err_info>

ERROR

Defined values

<ip_address>

A string parameter that identifies the IP address of current active socket PDP.

<err_info>

A string parameter that displays the cause of occurring error.

Examples

AT+CNETIPADDR?

+CNETIPADDR: 10.71.155.118

16.4 Unsolicited CNETSTART/CNETSTOP Codes

Code of <err> Description

0 Operation succeeded
