Smart Machine Smart Decision

SIM7500_SIM7600 Series_AT Command Manual_V1.07 2017-12-25

352

The status of HTP module:

Updating: HTP module is synchronizing date time

NULL: HTP module is idle now

<err>

The result of the HTP updating

Examples

AT+CHTPUPDATE

+CHTPUPDATE: 0

15.7.3 Unsolicited HTP Codes

Code of <err>

Description

0 Operation succeeded

1 Unknown error

Wrong parameter

Wrong date and time calculated

4 Network error

15.8 NTP

These AT Commands of NTP related are used to synchronize system time with NTP server.

15.8.1 AT+CNTP update system time

Description

This command is used to update system time with NTP server.

SIM PIN References

YES Vendor

Syntax

Test Command Responses

AT+CNTP=? +CNTP: 64,(-47~48)

Read Command Responses
