Smart Machine Smart Decision

SIM7500_SIM7600 Series_AT Command Manual_V1.07 2017-12-25

Execution Command

Responses

AT+CPAS +CPAS: <pas>

Defined values

<pas>

0 – ready (ME allows commands from TA/TE)

3 – ringing (ME is ready for commands from TA/TE, but the ringer is active)

4 – call in progress (ME is ready for commands from TA/TE, but a call is in progress)

Examples

RING (with incoming call)

AT+CPAS

+CPAS: 3

AT+CPAS=?

+CPAS: (0,3,4)

4.20 AT+SIMEI Set IMEI for the module

Description

This command is used to set the module’s IMEI value.

SIM PIN References

NO Vendor

Syntax

Test Command Responses

AT+SIMEI=?

Read Command Responses

AT+ SIMEI?

+SIMEI: <imei>

Write Command Responses

AT+SIMEI=<imei> OK

ERROR

Defined values
