SIM7500_SIM7600 Series_AT Command Manual_V1.07 2017-12-25

338

Examples

AT+CFTPSSINGLEIP=1

AT+CFTPSSINGLEIP?

+CFTPSSINGLEIP:1

AT+CFTPSSINGLEIP=?

+CFTPSSINGLEIP: (0,1)

15.4.14 AT+CFTPSCACHERD Output cached data to MCU

Description

This command is used to output cached data(generated by AT+CFTPSGET/

AT+CFTPSLIST) to

MCU.

SIM PIN References

YES Vendor

Syntax

Read Command Responses

AT+CFTPSCACHERD? +CFTPSCACHERD: <len>

Execute Command Responses

AT+CFTPSCACHERD

If cache data is AT+CFTPSGET:

+CFTPSGET: DATA,<out_len><CR><LF>

…

If the cache data is AT+CFTPSLIST:

+CFTPSLIST: DATA,<out_len><CR><LF>

…

ERROR

Defined values

<len>

The bytes of data cached in FTPS module.

<out_len>
