Smart Machine Smart Decision

SIM7500_SIM7600 Series_AT Command Manual_V1.07 2017-12-25

194

Examples

AT+CGREG=?

+CGREG: (0-1)

AT+CGREG?

+CGREG: 0,0

9.2 AT+CGATT Packet domain attach or detach

Description

The write command is used to attach the MT to, or detach the MT from, the Packet Domain service.

The read command returns the current Packet Domain service state.

SIM PIN References

YES 3GPP TS 27.007

Syntax

Test Command Responses

AT+CGATT=? +CGATT: (list of supported <state>s)

ERROR

Read Command Responses

AT+CGATT? +CGATT: <state>

4 – unknown

5 – registered, roaming

<lac>

Two bytes location area code in hexadecimal format (e.g.”00C3” equals 193 in decimal).

NOTE: The <lac> not supported in CDMA/HDR mode

<ci>

Cell ID in hexadecimal format.

GSM : Maximum is two byte

WCDMA : Maximum is four byte

TDS-CDMA : Maximum is four byte

NOTE: The <ci> not supported in CDMA/HDR mode
