5-9
Pt. TYPE: S2STAGE Description: 2 Stage Monitor
Circuit Status LCD Readout (2
nd
line) LED
Normal 2 Stage Monitor NORMAL
Limited 2 Stage Monitor ALARM A
Open 2 Stage Monitor TROUBLE T
Short 2 Stage Monitor ALARM A
Disable TBL 2 Stage Monitor TROUBLE T
Class A TBL 2 Stage Monitor TROUBLE T
Detailed Description: Used for 2 Stage Alarms. The current limited operation
of any device will indicate a STAGE 1 ALARM (press the <ö> key to
display). The shorting of the circuit, such as a key switch operation, will cause
a STAGE 2 ALARM (press the <ö> key to display).
Figure 5-24. S2STAGE Point Type
Pt. TYPE: SO Description: Sprinkler Supv (normally open)
Circuit Status LCD Readout (2
nd
line) LED
Normal Sprinkler Monitor NORMAL
Limited Sprinkler Monitor SUPERVISORY S
Open Sprinkler Monitor TROUBLE T
Short Sprinkler Monitor SUPERVISORY S
Disable TBL Sprinkler Monitor TROUBLE T
Class A TBL Sprinkler Monitor TROUBLE T
Detailed Description: Used to indicate sprinkler abnormal conditions such as
the operating of a PIV or OS&Y tamper switch. Must be used with normally
open contacts only.
Figure 5-25. SO Point Type
Pt. TYPE: SC Description: Sprinkler Supv (normally closed)
Circuit Status LCD Readout (2
nd
line) LED
Normal Sprinkler Monitor SUPERVISORY S
Limited Sprinkler Monitor NORMAL
Open Sprinkler Monitor TROUBLE T
Short Sprinkler Monitor TROUBLE T
Disable TBL Sprinkler Monitor TROUBLE T
Class A TBL Sprinkler Monitor TROUBLE T
Detailed Description: Used the same as SO except the contacts monitored must
be normally closed and a shunt resistor used. This type assures the zone will
not go into alarm with multiple tamper valves activated. Refer to Field Wiring
Diagram page 7 if 4-Point IDC 565-473 is used; or page 11 for a 4-Point IDC
565-610.
Figure 5-26. SC Point Type
Continued on next page
Point Type Messages for Monitor Points, Continued
Monitor Points (continued)
