Simplex 4005 Programming Instructions

5-18
Pt. TYPE: PRIMARY Description: Elevator Capture (primary)
Operates on General Alarm
Circuit Status LCD Readout (2
nd
line) LED
Normal Pri Elevator Capture ON
Normal Pri Elevator Capture OFF
Normal Pri Elevator Capture CODING
Open Pri Elevator Capture TROUBLE T
Short Pri Elevator Capture TROUBLE T
Disable TBL Pri Elevator Capture TROUBLE T
Off Auto TBL Pri Elevator Capture TROUBLE T
Detailed Description: Used for any relay connected to the elevator controls to
provide primary floor elevator capture. By default, these relays pick on any
alarm.
Figure 5-46. PRIMARY Point Type
Pt. TYPE: ALTERN Description: Elevator Capture (alternate)
Circuit Status LCD Readout (2
nd
line) LED
Normal Alt Elevator Capture ON
Normal Alt Elevator Capture OFF
Normal Alt Elevator Capture CODING
Open Alt Elevator Capture TROUBLE T
Short Alt Elevator Capture TROUBLE T
Disable TBL Alt Elevator Capture TROUBLE T
Off Auto TBL Alt Elevator Capture TROUBLE T
Detailed Description: Used for any relay connected to the elevator controls to
provide alternate floor elevator capture.
Figure 5-47. ALTERN Point Type
Pt. TYPE: AHUR Description: AHU On / Off (single relay control)
Operates on General Alarm
Circuit Status LCD Readout (2
nd
line) LED
Normal AHU Relay ON
Normal AHU Relay OFF
Normal AHU Relay CODING
Open AHU Relay TROUBLE T
Short AHU Relay TROUBLE T
Disable TBL AHU Relay TROUBLE T
Off Auto TBL AHU Relay TROUBLE T
Detailed Description: Used where one auxiliary relay performs AHU ON and
OFF control.
Figure 5-48. AHUR Point Type
Continued on next page
Point Type Messages for Signal Points, Continued
Signal Points (continued)
