Simplex 4005 Programming Instructions

5-17
Pt. TYPE: RWATER Description: Water Signal (on until Reset)
Circuit Status LCD Readout (2
nd
line) LED
Normal Waterflow Signal ON
Normal Waterflow Signal OFF
Normal Waterflow Signal CODING
Open Waterflow Signal TROUBLE T
Short Waterflow Signal TROUBLE T
Disable TBL Waterflow Signal TROUBLE T
Off Auto TBL Waterflow Signal TROUBLE T
Detailed Description: Used in applications where a waterflow signal circuit is
required which will remain activated until the reset key is pressed. Activated
from any WATER point type.
Figure 5-44. RWATER Point Type
Pt. TYPE: SUPV Description: Sprinkler Supervisory Signal (until
acknowledged)
Circuit Status LCD Readout (2
nd
line) LED
Normal Supervisory Signal ON
Normal Supervisory Signal OFF
Normal Supervisory Signal CODING
Open Supervisory Signal TROUBLE T
Short Supervisory Signal TROUBLE T
Disable TBL Supervisory Signal TROUBLE T
Off Auto TBL Supervisory Signal TROUBLE T
Detailed Description: Used in applications where a supervisory signal circuit is
required which will remain ON until acknowledged.
Figure 5-45. SUPV Point Type
Continued on next page
Point Type Messages for Signal Points, Continued
Signal Points (continued)
Technical Manuals Online! - http://www.tech-man.com

Simplex 4005 Specifications

General

Brand	Simplex
Power Supply	24 VDC
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	Up to 93% RH, non-condensing
Compatibility	Compatible with Simplex fire alarm control panels
