Simplex 4005 Programming Instructions

5-16
Pt. TYPE: SVISUAL Description: Visual (on until silence)
Operates on General Alarm
Circuit Status LCD Readout (2
nd
line) LED
Normal Visual ON
Normal Visual OFF
Normal Visual CODING
Open Visual TROUBLE T
Short Visual TROUBLE T
Disable TBL Visual TROUBLE T
Off Auto TBL Visual TROUBLE T
Detailed Description: Used only with visuals that are required ON until the
alarm silence key is pressed.
Figure 5-41. SVISUAL Point Type
Pt. TYPE: RVISUL Description: Visual (on until silence)
Operates on General Alarm
Circuit Status LCD Readout (2
nd
line) LED
Normal Visual ON
Normal Visual OFF
Normal Visual CODING
Open Visual TROUBLE T
Short Visual TROUBLE T
Disable TBL Visual TROUBLE T
Off Auto TBL Visual TROUBLE T
Detailed Description: Used only with visuals that must remain ON until the
system reset key is pressed.
Figure 5-42. RVISUL Point Type
Pt. TYPE: SWATER Description: Water Signal (on until Silence)
Circuit Status LCD Readout (2
nd
line) LED
Normal Waterflow Signal ON
Normal Waterflow Signal OFF
Normal Waterflow Signal CODING
Open Waterflow Signal TROUBLE T
Short Waterflow Signal TROUBLE T
Disable TBL Waterflow Signal TROUBLE T
Off Auto TBL Waterflow Signal TROUBLE T
Detailed Description: Used in applications where a waterflow signal circuit is
required which will remain activated until the silence key is pressed. Activated
from any WATER point type.
Figure 5-43. SWATER Point Type
Continued on next page
Point Type Messages for Signal Points, Continued
Signal Points (continued)
