Simplex 4005 Programming Instructions

2-14
Table 2-3 lists the Output Mode choices for a Generic Output Point and the
Points to which they can be linked.
Table 2-3. Generic Output Point Output Mode and their
Link to… Choices
Edit Mode Programming, Continued
Edit Mode Programming
Generic Output
Output Mode…
SMPL
Fire
Supervisory
Trouble
Disabled
ON
OFF
…Can Link to these Points:
No Points (RCU/SCU will not respond to
any Output Mode)
System Points (see complete list in
Chapter 5)
Digital Pseudo Points (see complete list in
Chapter 5)
Lists (see complete list in Chapter 5)
