Spectra Precision Focus 30 - Assembly telescope covers

Chapter 5
Maintenance and Repair
P/N 79000035_SM, Version 1.5 5 - 3 Focus 30/35 Service Manual
Assembly telescope covers
Performance
Item Performance Action Result Notes
1 Mount the Telescope
covers.
Press the Cover
slightly down with one
hand, make sure the
Rubber plugs are
positioned
correctly(only in
Distance unit cover),
see See Fig. 5-2 on
page 1-3.
Fig. 5-2 Rubber plug position
