Chapter 3
Theory of Operation
P/N 79000035_SM, Version 1.5 3 - 47 Focus 30/35 Service Manual
Fig. 3-44 Optical plummet
Service
Maintenance
Alignment of optical plummet.
Replacement of service parts
• Optical plummet
Focus
Crosshair
Eyepiece
