Spectra Precision Focus 30 Service Manual

Chapter 1
General Information and Safety
Focus 30/35 Service Manual 1 - 8 P/N 79000035_SM, Version 1.5
Laser Safety
Class I, II, and IIIa laser products are defined by the U.S. Bureau of Radiological Health.
C
Warning – Use of controls or adjustments or performance of procedures other than those
specified herein may result in hazardous LED or laser radiation exposure. As with any bright light
source, such as the sun, electric welding arcs or arc lamps, common sense applies.
DO NOT look into the laser aperture when the laser is on. For further information regarding safe
use of lasers, refer to the IEC standard 60825-1 2007.
This equipment has been tested and found to comply with IEC 60825-1 July 2007, 21 CFR 1040.10,
and 1040.11 except for deviations pursuant to Laser Notice No. 50, dated July 26, 2001.
Queries
Address any questions you may have about laser safety to:
Trimble Navigation Limited 5475 Kellenburger Road Dayton, OH USA 45424-1099 Attention:
Laser Safety Officer, Quality Assurance Group Phone (937) 233-8921 ext 5824 or (800) 538-7800
Fax (937) 233-9661
Spectra Precision Focus 30 Total Station
The Spectra Specision Focus 30 is a CLASS 3R LASER PRODUCT
Fig. 1-2 Laser warning label
The instrument contains visible and invisible laser sources:
• The laser diode for distance measuring in DR- mode and laser pointer function operating at
660 nm (red, visible light), with a beam divergence of 0.4x0,4 mrad and an output power of
<5mW, while the emission is coaxial with the telescope. This mode operates in LASER
CLASS 3R.
• The laser diode for distance measuring in prism mode operates at 660 nm (red, visible light),
with a beam divergence of 0.4x0,4 mrad and an output power of < 20 µW, while the emission
is coaxial with the telescope. This mode operates in LASER CLASS 1.
• The laser diode for Tracker operates at 850 nm (infrared, non-visible light), with a beam
divergence of 40x40 mrad and an output power of < 0.1 mW, while the emission is coaxial
LASER RADIATION
AVOID DIRECT EYE EXPOSURE
CLASS 3R LASER PRODUCT
Wavelength: 630-680nm
Maximum output power: 5mW
This product complies with
IEC 60825-1: 2007 and
21 CFR 1040.10 and 1040.11
Except for deviations pursuant
to Laser Notice no.50,
dated June 24, 2007

Spectra Precision Focus 30 Specifications

General

Brand	Spectra Precision
Model	Focus 30
Category	Measuring Instruments
Language	English
