Spectra Precision Focus 30 Service Manual

Chapter 5
Maintenance and Repair
P/N 79000035_SM, Version 1.5 5 - 53 Focus 30/35 Service Manual
Control Unit F30
• Remove Control Unit F30
• Disassembly / Assembly Control Unit F30
Tools and equipment
Remove Control Unit F30
Performance
Description Part number
Torx T8 bit; T6 bit Local tool
Torque wrench 120 Ncm T71600280
Grease ISOFLEX 3000 571905945
Item Performance Action Result Notes
1 Remove Side cover
right.
see page 5-27
2 Loose Side cover
left.
Loose only the four
fixing screws and lift the
cover a bit, see page 5-
31.
The Control unit F30
becomes loose.
3 Disconnect cables. Disconnect three cables
from MCBsee page 3-
59.
4 Disassemble
Control Unit F30.
A. Remove two
screws.
B. Unhook the control
unit downward.
C. Pull out the four
cables through the
opening left from
MCB.
D. Mount the parts in
reverse order and
tighten the two
screws see Fig. 5-
43 on page 5-54 .
60Ncm/5,31 lbfin Torque wrench
TORX 8
Attend the 4 cables
from MCB & SCK/
BT to ACB.
