Spectra Precision Focus 30 Service Manual

Chapter 5
Maintenance and Repair
P/N 79000035_SM, Version 1.5 5 - 9 Focus 30/35 Service Manual
Reticle
• Reticle replacement
Tools and equipment
Reticle replacement
Performance
Description Part number
Torx T8 bit Local tool
Torque wrench 120 Ncm T71600280
Reticle erecting tool 79290035
Item Performance Action Result Notes
1 Replace Reticle. A. Unscrew the
Eyepiece.
B. Clip off the
Cover.
C. Unscrew three
screws.
D. Remove the
mounted
Reticle.
E. Exchange parts
and remount it in
reverse order.
60Ncm/5,31bfin
Lubricate the O-ring
with Isoflex3000.
