Chapter 5
Maintenance and Repair
P/N 79000035_SM, Version 1.5 5 - 51 Focus 30/35 Service Manual
USB connector
• Replace USB connector
Tools and equipment
Replace USB connector
Performance
Description Part number
Torx T6 bit Local tool
Torque wrench 120 Ncm T71600280
Item Performance Action Result Notes
1 Replace USB
connector.
A. Remove the
two screws.
B. Remove USB
connector until
you reach the
cable.
C. Unplug the
cable FCB2-
SRBH.
D. Exchange the
USB connector
and mount it in
reverse order.
Torque wrench
Torx T6
20Ncm/1,77bfin
