Spectra Precision Focus 30 Service Manual

Chapter 4
Troubleshooting
Focus 30/35 Service Manual 4 - 12 P/N 79000035_SM, Version 1.5
Basic funtion test
Basic function test is a software module to show all sensors status information and provides a basic
function test for all subsystems.
Check unites states, basic measure function & units
Performance
Item Performance Action Result Notes
1 Start up instrument /
PASS.
See page 7-3 how to set-
up the instrument.
2 Track Unit States Select
Track unit status
from
Basic function test in
Analyze, see Fig. 4-7 on
page 4-12 .
Fig. 4-7 Track Unit states
