Chapter 5
Maintenance and Repair
Focus 30/35 Service Manual 5 - 62 P/N 79000035_SM, Version 1.5
2nd Battery compartment Focus F35 RX
• Remove 2nd Battery compartment
• Exchange 2nd Battery compartment door
Tools and equipment
Remove 2nd Battery compartment
Performance
Description Part number
Torx T8 bit; T6 bit Local tool
Torque wrench 120 Ncm T71600280
Grease ISOFLEX 3000 571905945
Item Performance Action Result Notes
1 Remove Side cover
right.
see page 5-27
2 Loose Side cover
left.
Loose only the four
fixing screws and lift the
cover a bit, see page 5-
31.
The 2nd Battery
compartment
becomes loose.
3 Disconnect cable. Disconnect one cable
from MCB see page 3-
59.
4 Disassemble 2nd
Battery
compartment.
A. Remove two
screws.
B. Unhook the 2nd
Battery
compartment
downward. Give
attention to the two
springs.
C. Pull out the cable
through the
opening left from
MCB.
D. Mount the parts in
reverse order and
tighten the two
screws see Fig. 5-
43 on page 5-54 .
60Ncm/5,31 lbfin Torque wrench
TORX 8
The springs opens
the battery lid
softly.
Attend the cable
from MCB.
