Spectra Precision Focus 30 Service Manual

Chapter 5
Maintenance and Repair
P/N 79000035_SM, Version 1.5 5 - 15 Focus 30/35 Service Manual
Disassembly/Assembly Receiver board
Performance
Item Performance Action Result Notes
1 Remove Distance
unit cover.
see page 5-2
2 Disconnect cables. A. Unplug the
coaxial cable.
B. Loosen the
screw and take
out the
Reference fibre
ferule.
C. Disconnect TSF-
TLD cable.
D. Unplug the cable
of filter motor.
E. Disconnect TSF-
REC cable.
The Reference fibre
stays in the fibre
bender clip.
Allen key 0,7mm
5Ncm/0,44lbfin
