Spectra Precision Focus 30 Service Manual

Chapter 6
Adjustment and Verification
P/N 79000035_SM, Version 1.5 6 - 111 Focus 30/35 Service Manual
Battery/radio side cover
• Radio range test
• Radio short range test
Tools and equipment
Radio configuration - Global or France
Performance
Description Part number
Instrument F2 menu
Georadio 2.4 range test cable 59300001
External Controller unit with radio
Item Performance Action Result Notes
1 Start up instrument. See User manual how to
set-up the instrument.
2 Start configuration
menu Radio
Parameter.
A. Select
Radio
Parameter and
configure Radio
Channel and
Network ID on the
instrument and
external device.
The external
radio have to be
configured
according the
instrument
settings!
Menu description on
F2 panel:
Main Menu/Radio
Parameter.
3 Configure Radio in
Global or French.
A. Select
Service from
Main Menu.
B. Select from
Service
Menu
the Radio
config
.
C. Choose the radio
configuration
Gloabal
or
France. The menu
Radio config will be
left automatically.
D. Connect correct
configured
instrument and
external controller to
test the connection
according user
manual.
The radio is now
configured in
Global or
France.
Connection
have to be
established.
Menu description on
F2 panel:
Main Menu/Service
Menu/Radio config.
