Spectra Precision Focus 30 Service Manual

Chapter 5
Maintenance and Repair
P/N 79000035_SM, Version 1.5 5 - 25 Focus 30/35 Service Manual
Tracklight
• Disassembly/Assembly Tracklight
Tools and equipment
Disassembly/Assembly Tracklight
Performance
Description Part number
Torx T8 bit Local tool
Torque wrench 120 Ncm T71600280
Prism min. 50mm Local tool
Item Performance Action Result Notes
1 Remove Servo
focus unit cover.
see page 5-2
2 Exchange
Tracklight.
A. Unscrew two
screws, to remove
only the Tracklight,
or see (E).
B. Unplug the cable.
C. Lift off the
Tracklight modul.
D. Exchange the
Tracklight and
mount the parts in
reverse order.
E. Unscrew two
screws, to remove
the Tracklight with
holder.
Torque wrench
Torx T8
60Ncm/5,31 lbfin
Torque wrench
Torx T8
60Ncm/5,31 lbfin
3 Align Tracklight. see page 6-103
4 Mount Servo focus
unit cover.
see page 5-3
