Spectra Precision Focus 30 Service Manual

Chapter 5
Maintenance and Repair
Focus 30/35 Service Manual 5 - 36 P/N 79000035_SM, Version 1.5
Handle
• Handle parts replacement
Tools and equipment
Handle parts replacement
Performance
Description Part number
Torx T8 bit Local tool
Torx T10 bit Local tool
Torque wrench 120 Ncm T71600280
Item Performance Action Result Notes
1 Exchange handle
parts.
A. Remove the two
screws with
washer.
B. Pull out the two
Plastic wedges.
C. Take down the
Handle cover
rubber.
D. Unscrew the two
screws.
E. Remove the
Handle cover.
F. Replace handle
parts and mount
them in reverse
order.
Torque wrench
Torx T8
60 Ncm/5,31 lbfin
Torque wrench
Torx T10
100 Ncm/8,85 lbfin
