Spectra Precision Focus 30 Service Manual

Chapter 5
Maintenance and Repair
Focus 30/35 Service Manual 5 - 20 P/N 79000035_SM, Version 1.5
Exchange Holder receiver fibre
Performance
4 Assembly Exchange the
Transmitter unit and
mount the parts in
reverse order, attend the
laying of fibres see
Figure 5-13 and see Fig.
5-14 on page 5-18 .
Fig. 5-16 Remove Transmitter unit
4 Adjustment and
calibration
What to do after
replacement?
Item Performance Action Result Notes
1 Remove Distance
unit cover.
see page 5-2
2 Remove
Transceiver board.
see page 5-15
Item Performance Action Result Notes
A
longer screw
M2,5x14
C
B
