Chapter 5
Maintenance and Repair
P/N 79000035_SM, Version 1.5 5 - 39 Focus 30/35 Service Manual
Overview connectors and laying of cables - MCB
Fig. 5-31 Overview connectors - MCB
Fine motor V
Coarse motor V
Coarse motor Hz
Fine motor Hz
Display board-F2D
Servo knob board-SKB
Hz slip contact board-SCB
Solenoid Hz
Solenoid V
Tilt sensor
Battery connector
radio board
Angle control
board V-ACB
Angle control board Hz-ACB
3xApplication
control board-ACB
Jumper on right side
