Chapter 3

Theory of Operation

Focus 30/35 Service Manual 3 - 20 P/N 79000035_SM, Version 1.5

Tilt sensor

Location of tilt sensor

Fig. 3-18 Location of tilt sensor

Technical specification

Working range: Coarse measurement =  3,3gon; Fine measurement =  111mgon

Update rate = 4,7 times/sec

Accuracy: < 0,15mgon

Tilt sensor

Slip ring board

with coarse tilt

Coarse

tilt
