Spectra Precision Focus 30 Service Manual

Chapter 3
Theory of Operation
P/N 79000035_SM, Version 1.5 3 - 9 Focus 30/35 Service Manual
Block diagram
Fig. 3-7 Block diagram servo focus
The tracker servo focus bord is also controlling.
• Tracker camera board
• Tracklight
• Reticle illumination
Service
Maintenance
• Check of the mechanics, regreasing of spindle arm
• Check of correct positioning (supported by Service Software)
• Adjustment and calibration (supported by Service Software)
Replacement of service parts
• Tracker servo focus board
• Servo focus mechanic part
Tracker camera board
USB Hub
Servo focus
Controler
Tracker servo focus board
TCB
TSF
Track light LEDs
flex board
Slip ring board
Servo focus
motor
Reticle
illumination
