Chapter 3
Theory of Operation
P/N 79000035_SM, Version 1.5 3 - 59 Focus 30/35 Service Manual
Overview connectors - MCB board
Fig. 3-55 Overview connectors - MCB
Fine motor V
Coarse motor V
Coarse motor Hz
Fine motor Hz
Display board-F2D
Servo knob board-SKB
Hz slip contact board-SCH
Solenoid Hz
Solenoid V
Tilt sensor
Battery connector
radio board-BCRB
Angle control
board V-ACB
Angle control board Hz-ACB
3xApplication
control board-ACB
Jumper on right side
Battery2 compartment
