Spectra Precision Focus 30 Service Manual

Chapter 3
Theory of Operation
P/N 79000035_SM, Version 1.5 3 - 35 Focus 30/35 Service Manual
Base part F30 and USB connector
Location of Base part and foot connector
Fig. 3-33 Location of base part
Technical specification
Functional description
The Base part is assembled into one unit and not possible to open.
The Hirose connector is the communication connector and transmits the external power supply. The
foot connector board is connected via cable to the Hz slip ring board.
Base part F30
USB connector
Hirose
Slip ring board SRB
