Chapter 5
Maintenance and Repair
Focus 30/35 Service Manual 5 - 28 P/N 79000035_SM, Version 1.5
Servo knob board-SKB and Trigger key replacement
Performance
Fig. 5-22 Replace Side cover right - (Servos)
2 Adjustment and
calibration
What to do after
replacement?
Item Performance Action Result Notes
1 Remove Side cover
right.
see page 5-27
Item Performance Action Result Notes
A/F
D
E
35Ncm
3.1 lbfin
C
C
Cable
SCK-MCB
Cable
ACB-BT
