Spectra Precision Focus 30 Service Manual

Chapter 5
Maintenance and Repair
Focus 30/35 Service Manual 5 - 106 P/N 79000035_SM, Version 1.5
Horizontal servo drive unit
There are two versions of Horizontal servo drive unit in the instrument series. A adjustable and a
nonadjustable version exists.
• Disassembly / assembly Horizontal servo drive unit - nonadjustable version
• Disassembly / assembly Horizontal servo drive unit - adjustable version
Tools and equipment
Disassembly / assembly Horizontal servo drive unit - nonadjustable version
Performance
Description Part number
Torx T8 bit Local tool
Screw driver flat Local tool
Torque wrench 120 Ncm T71600280
Horizontal gear wheel Clamping tool 79294035
Item Performance Action Result Notes
1 Remove Side cover
right.
see page 5-27
2 Remove Vertical
servo drive unit.
see page 5-80
3 Remove MCB
board.
see page 5-42
4 Remove Side cover
left.
see page 5-31
5 Remove Base part. see page 5-45
6 Remove Optical
plummet.
see page 5-68
7 Remove Control
unit F2.
see page 5-65
8 Remove Slip
contacts Hz-SCH.
see page 5-72
