Chapter 4
Troubleshooting
Focus 30/35 Service Manual 4 - 4 P/N 79000035_SM, Version 1.5
Download constants
The 10 digit serial numbers for Focus 35/ RX are introduced since januar 2016.
To search for the instrument constant files on partners, combine the model code (3digits) with serial
number (10 digits), e.g. Model code Focus 35 RX (5“) 865 plus serial number 1550601296 to search
string number 8651550601296, or search with *1550601296*.
Refer also to bulletin JE-01-0116-000 and, see “Models and serial numbers” on page 2-3.
2 Save constants from
instrument.
A. Select
Save constants
from instrument to PC
from Instrument data
in
Analyze and
pressRun Operation.
B. Press
Collect data in
the module
Info
Report Generator, see
Fig. 4-1 on page 4-2 .
C. Press
Store complete
report in the module
Focus Info Report
Generator
.
D. Press
Open to store
the file.
The module
Focus Info
Report
Generator
appears.
Collecting data
from all sensors.
Instrument
report file *.irep
will be created
in a selected
folder.
The *.irep file
contains all
instrument data and
events & error logs.
The file name
contains the serial
number and current
date information.
Fig. 4-3 Save constants from instrument to PC
4 Exit the program. Press the
Close button to
exit the program.
