Spectra Precision Focus 30 Service Manual

Chapter 5
Maintenance and Repair
P/N 79000035_SM, Version 1.5 5 - 121 Focus 30/35 Service Manual
What to do after replacement?
This table is a short form instruction of reqired adjustments and checks/tests after repair/service.
When replacing a unit such as Tilt sensor more boards / modules might need to be replaced.
Performance
Item Board / module re-
placed
Adjustment Check / Test
1 No parts replaced Service check list
2 Reference fibre Reference fibre adjustment Service check list
3 Receiver fibre Receiver fibre adjustment
Reference fibre adjustment
Verify Reference fibre, signals
and distance measurement
EDM offset determination
Service check list
4 Exchange Holder
receiver fibre
Receiver fibre adjustment
Reference fibre adjustment
Verify Reference fibre, signals
and distance measurement
EDM offset determination
Service check list
5 Transmitter unit F30 Transmitter Unit F30 adjustment /
Laser pointer
Receiver fibre adjustment
Reference fibre adjustment
Tracker transmitter adjustment
Verify Reference fibre, signals
and distance measurement
Check motors
Tracker test
EDM offset determination
Service check list
6 Receiver unit F30 Transmitter Unit F30 adjustment /
Laser pointer
Receiver fibre adjustment
Reference fibre adjustment
Verify Reference fibre, signals
and distance measurement
Check motors
EDM offset determination
Service check list
7 EDM F35 High
Precision 1mm
Transmitter Unit F30 adjustment /
Laser pointer
Receiver fibre adjustment
Reference fibre adjustment
Tracker transmitter adjustment
Verify Reference fibre, signals
and distance measurement
Check motors
Tracker test
Service check list
EDM offset determination
Focus 35 EDM 1mm - Verify the
1mm accuracy
