Spectra Precision Focus 30 Service Manual

Chapter 6
Adjustment and Verification
Focus 30/35 Service Manual 6 - 86 P/N 79000035_SM, Version 1.5
Tracker unit
• Tracker transmitter adjustment
• Tracker receiver unit alignment
• Tracker test
• Tracker collimation
Tools and equipment
Tracker transmitter adjustment
Performance
Description Part number
Tracker transmitter adjustment tool 79351019
Illumination Adapter Collimator (white/green) 79299035
Screw driver Torx T8 Local tool
Allan key 2mm Local tool
Allan key 1,5mm Local tool
Prism 62mm SECO Silver coated water sealed <2” 6411-04-BLK
Item Performance Action Result Notes
1 Precondition: See “Transmitter Unit
F30 adjustment / Laser
pointer” on page 6-51.
The Transmitter
unit F30 is well
adjusted.
2 Prepare instrument/
PASS.
A. Mount the instrument
on the Collimator
bench.
B. See “Connect to the
Unit” on page 7-3.
how to set-up the
instrument.
C. Remove distance unit
cover Fig. 5-1 on
page 1-2
