Spectra Precision Focus 30 Service Manual

Chapter 5
Maintenance and Repair
Focus 30/35 Service Manual 5 - 30 P/N 79000035_SM, Version 1.5
Board BT Blue Tooth replacement
Performance
Item Performance Action Result Notes
1 Blue Tooth
replacement.
A. Remove Side cover
right, see page 5-
27.
B. Remove Board
SCK, see page 5-
28.
C. Remove four
screws.
D. Exchange the Blue
Tooth board.
E. Mount the parts in
reverse order and
tighten the four
screws.
Torx T6
Torque wrench T6
35 Ncm/3,1 lbfin
Fig. 5-24 Blue tooth replacement
2 Adjustment and
calibration
What to do after
replacement?
C
D
35Ncm/ 3.1 lbfin
