Spectra Precision Focus 30 Service Manual

Chapter 5
Maintenance and Repair
P/N 79000035_SM, Version 1.5 5 - 5 Focus 30/35 Service Manual
Servo focus unit F30
• Servo focus replacement
• Board TSF - Tracker servo focus - replacement
Tools and equipment
Servo focus replacement
Performance
Description Part number
Torx T8 bit Local tool
Torque wrench 120 Ncm T71600280
Item Performance Action Result Notes
1 Remove Telescope
tracker cover.
see page 5-2
2 Remove Track light. see page 5-25
3 Disconnect the
cables.
see Fig. 5-4 on page
5-6
