Spectra Precision Focus 30 Service Manual

Chapter 5
Maintenance and Repair
P/N 79000035_SM, Version 1.5 5 - 11 Focus 30/35 Service Manual
Distance unit
• Exchange Reference fibre
• Exchange Receiver fibre
• Disassembly/Assembly Receiver board
• Disassembly/Assembly Transmitter unit
• Exchange Holder receiver fibre
• Exchange EDM F35 High Precision 1mm
Tools and equipment
Exchange Reference fibre
Performance
Description Part number
Torx T8 bit Local tool
Torque wrench 120 Ncm T71600280
Allen key 0,7mm Local tool
Item Performance Action Result Notes
1 Remove Distance
unit cover.
see page 5-2
2 Remove Reference
fibre.
A. Unscrew the
clamp screw on
Receiver board.
B. Pull out the
Reference fibre
ferule.
C. Unscrew the
clamp screw on
Transmitter.
D. Pull out the
Reference fibre
ferule.
E. Click out the Fibre
bender clip in
direction of the red
arrows and take off
the complete
Reference fibre.
Allen key 0,7mm
5Ncm/0,44lbfin
Allen key 0,7mm
5Ncm/0,44lbfin
Not necessary if
previous version of
fibre bender
without clip is used.
