Spectra Precision Focus 30 Service Manual

Chapter 5
Maintenance and Repair
Focus 30/35 Service Manual 5 - 122 P/N 79000035_SM, Version 1.5
8 Tracker receiver Tracker receiver unit alignment Tracker test
Service check list
9 Servo focus unit F30 Clean and regrease
(maintenance)
Check Servo Focus Unit F30
specifications
Servo Focus Unit HA/VA
collimation short range test
Check of Reticle illumination
Service check list
10 Track light F30 Tracklight alignment Service check list
11 Control unit F30 Control Unit F30 - Display,
Touch Screen and Keyboard test
Service check list
12 2nd Battery
compartment
Service check list
13 Control unit F2 Adjustment of Optical Plummet Face 2 panel - Display and
Keyboard test
Service check list
14 Optical plummet F30 Adjustment of Optical Plummet Service check list
15 Main control board
MCB
Write constants from PC to
instrument
Vertical Drive adjustment (for
adjustable drive only)
Service Interval
Service check list
16 Slip contacts Hz
board with Coarse tilt
sensor
Calibration Coarse tilt sensor Service check list
17 Tilt sensor Calibration Fine tilt sensor
Calibration Coarse tilt sensor
Adjustment of Optical Plummet
Horizontal Coarse drive lever
arm adjustment
Vertical Drive adjustment (for
adjustable drive only)
Horizontal Drive adjustment (for
adjustable drive only)
Service check list
Item Board / module re-
placed
Adjustment Check / Test
