Chapter 5
Maintenance and Repair
Focus 30/35 Service Manual 5 - 40 P/N 79000035_SM, Version 1.5
Fig. 5-32 Laying of cables - MCB
Blue tooth
Batterry/ radio
connector
Hz slip contact
board
Solenoid
Hz
Angle control
board Hz
Solenoid Hz
Servo knob
board
Fine V
Coarse V
Coarse Hz
Fine Hz
Display
F2
Cable
holder
Cable
holder
