Spectra Precision Focus 30 Service Manual

Chapter 5
Maintenance and Repair
Focus 30/35 Service Manual 5 - 22 P/N 79000035_SM, Version 1.5
Performance
Item Performance Action Result Notes
1 Disassemble the
Receiver RX
Take out the RX board with receiver fibre.
Follow the instruction, see“Disassembly/
Assembly Receiver board” on page 5-15.
2 Exchange TX. Exchange the TX unit with reference fibre.
Follow the instruction, see“Disassembly/
Assembly Transmitter unit” on page 5-18.
3 Exchange RX Assemble the RX board with receiver fibre.
Follow the instruction, see“Disassembly/
Assembly Receiver board” on page 5-15.
4 Adjustment and
calibration
What to do after
replacement?
Fig. 5-18 EDM High Precision 1mm
