Spectra Precision Focus 30 Service Manual

Chapter 6
Adjustment and Verification
P/N 79000035_SM, Version 1.5 6 - 3 Focus 30/35 Service Manual
Fig. 6-1 SFU with holder for maintenance
3 Start up instrument /
PASS.
See “Connect to the Unit”
on page 7-3. how to set-up
the instrument.
Face two display
shows:
Error
Subsystem error:
DistV3
, press OK.
4 Start the test. Select
Servo Focus
Maintenance
from Servo
Focus
in Maintenance &
Service.
Note – Be aware of
short-circuit, the unit
has to be kept in
switched on mode.
5 Preparation of
maintenance.
A. Select
Servo Focus
Unit Adjust check
box.
B. Click
Adjust or use
short-cut key A.
The focusing lens is
running to defined
start position.
Item Performance Description Result Notes
Removable lens protective cover
A
B
C
Holder
