Spectra Precision Focus 30 Service Manual

Chapter 6
Adjustment and Verification
P/N 79000035_SM, Version 1.5 6 - 27 Focus 30/35 Service Manual
Fig. 6-18 Reticle adjustment
5 Store HA / VA
correction values.
A. Reaching the
adjustment tolerance,
the correction values
can be stored.
B. Save the correction
values pushing
Yes in
the message box.
If the correction value
are CHz <30cc and
CV <83cc, the
message box
Store
new corrections?
appears.
Item Performance Action Result Notes
C Vertical adjustment screw
B-Horizontal adjustment screw
