Spectra Precision Focus 30 Service Manual

Chapter 6
Adjustment and Verification
P/N 79000035_SM, Version 1.5 6 - 71 Focus 30/35 Service Manual
4 Check Filter motor. A. Select Check Filter
Motor and press the
button Start.
B. Confirm the test
results by pressing
Yes or No button.
Confirm the
observation and
the test result is
shown in
Program status/
messages
.
Observe the
movement of the
motor and listen
carefully at least 15-
20 times. You have to
hear a clear stop noise
of the Filter motor.
Fig. 6-56 Check Filter motor
5 Check Grey wedge
motor.
A. Select
Check Grey
Wedge
and click
Start.
B. Check the results and
confirm
OK.
Grey wedge
motor test is
successful
passed, when all
steps marked
with
PASS.
Item Performance Action Result Notes
