Spectra Precision Focus 30 Service Manual

Chapter 6
Adjustment and Verification
Focus 30/35 Service Manual 6 - 100 P/N 79000035_SM, Version 1.5
3 New Reference pixel
determination.
A. Aim to a SECO
prism at 50-100m in
face 1 and press in
Reference Pixel
Determination the
Start button.
B. Aim to prism in face
2 and press
Start
button.
C. If the new Ref pixel
is shown in green,
press
Save to store
the new Reference
pixel.
Trouble shooting:
If the the new Ref
pixel is shown in red
please check the
tolerance value and
repeat the
measurement.
Reference pixel
as coordinates in
X/Y in face 1 is
shown.
Reference pixel
as coordinates in
X/Y in face 2 is
shown.
The average of
the Ref pixel in
face 1/2 is
shown as the
new Ref pixel.
STD > 0,2:
Check
enviromental
conditions to
prism.
X1-X2 / Y1-Y2
pix:
Aim more
precise to prism
in face 1 and 2.
X/Y-direction
>35 pix:
Check reticle
adjustment with
Front lens
mirrow tool.
The software is
measuring 500 time
to prism.
Tolerance:
STD < 0,2 shown in
brackets.
Difference between
pixel in Face 1 and 2:
X1-X2  2 pix
Y1-Y2 pix
Difference between
Ref pixel to Defaults:
X-direction <35 pix
Y- direction <35 pix
Item Performance Action Result Notes
