Spectra Precision Focus 30 Service Manual

Chapter 6
Adjustment and Verification
P/N 79000035_SM, Version 1.5 6 - 105 Focus 30/35 Service Manual
4 Find adjustment
position.
A. Turn the instrument
in face 2 towards the
prism.
B. Click Holding mode
ON.
C. Hold a sheet of paper
on the prism and
align prism and
telescope to each
other.
D. 2/3 of transmitted
beam diameter
should be visible on
the edge of the prism
above.
E. The reflected
TrackLight beam
through the prism
should be visible on
the lower edge of the
prism.
F. Turn the prism to the
edges of the spots
one upon the other.
G. Go to item
6 for the
adjustment
procedere.
Servo focus unit
have to be
focused to
infinity.
The TrackLight
is visible on the
paper.
The reflex of the
TrackLight is
visible on the
paper.
The reflected
TrackLight
beam is visible
through the
eyepiece.
Do not touch the
focusing knob.
Item Performance Description Result Notes
