Spectra Precision Focus 30 Service Manual

Chapter 6
Adjustment and Verification
P/N 79000035_SM, Version 1.5 6 - 107 Focus 30/35 Service Manual
5 Preparation for
Tracklight alignment
with
CollimatorMonitor
software.
A. Refer to item 1 and
use the original
Tripod of the F35.
B. Push in CM
Open the
camera and press
Collimator in
Calibration section.
C. Choose
Track Light in
Operation TS
section.
D. Put and switch on the
reticle illumination
tool (yellow LED)
and use the servo
knobs to centre the
instruments crosshair
in the green rectangle
AOI.
E. Use the manual mode
CTRL+M to set the
crosshair to the
centre, press Done
and follow the
appearing
instructions.
F. Select in PASS
Adjustment
Tracklight
check box
and switch
On only
the green diode, see
Fig. 6-84 on page 6-
104 .
The hight Track
light lense to
base, should be
31,5 cm.
Follow the
instructions of
the program to
calibrate the
screen pattern.
press the
Done
button to reach
the next action.
The blue
measurement
frame appears
with a green
rectangle AOI.
The green edge
appears in CM
software, see
Fig. 6-87 on
page 6-108 .
Turn out the
instrument hight
adapter to position1
of the scale.
The Collimator
monitor software
(CM) has already
started with
configured
instrument type.
Refer also to the
Software user guide
chapter in the Trimble
Collimator Bench
manual on:
Collimator Bench
manual
Item Performance Description Result Notes
