Chapter 3

Theory of Operation

Focus 30/35 Service Manual 3 - 52 P/N 79000035_SM, Version 1.5

Fig. 3-48 Battery/radio side cover

The Battery/radio side cover includes:

• Internal battery compartment

• Radio module

• Connector board to internal battery, with Backup module.

Sealing

Internal battery

Radio module

Connector board

Side cover left

Battery cover
