Number Component Description
5 EE Port/Right
Magazine Access
Door
Provides access to the magazine and EE port on the
right side of the module.
6 Error LED - Amber
Controller Module Only - This LED illuminates when
the library detects an unrecoverable tape drive or
library error and is not capable of operation. Details of
the error are displayed on the front panel screen.
7 Attention LED -
Amber
Controller Module Only - This LED illuminates when
the library detects a condition which requires manual
intervention, but the library can still perform most
operations.
8 Clean LED - Amber
Controller Module Only - This LED illuminates when
a tape drive cleaning is needed.
9 Ready LED - Green
Controller Module Only - This LED is steady green
when the library is on, and blinks green when there is
library robotics activity.
10 Unit Identification
LED - Blue
Controller Module Only - The unit identification
LEDs on the front and back of the controller module
are controlled by a user through the OCP and RMI
Maintenance > UID LED Control screen. These lights
are helpful for locating the library in a data center.
