Spectra Stack Tape Library - Rear Panel Overview

REAR PANEL
This section describes the features accessible from the rear panel of the library.
Figure4 The rear view of the Spectra Stack library.
Number Component Description
1 Power Supplies
1 (standard) or 2 (redundant)
2 Chassis Fan
Provides cooling for the library module.
3 Controller Health
Status LED - Green
Indicates the module controller is operating normally.
4 Upper Expansion
Module Connection
Port
If there is a module above this module, a cable
connects from this port to the Lower Expansion
Module Connection Port in the upper module.
JANUARY 2023 34
SPECTRA STACK LIBRARY
USER GUIDE
CHAPTER 1 - PRODUCT OVERVIEW
