Number Component Description
5 USB Port
Controller Module Only
6 Ethernet Ports
Controller Module Only - Only one Ethernet port is
usable.
7 Lower Expansion
Module Connection
Port
If there is a module below this module, a cable
connects from this port to the Upper Expansion
Module Connection Port in the lower module.
8 Unit Identifier LED
- Blue
9 Drive Bays
Half-height drive bays shown. Full-height drives use
the space of two half-height drive bays.
10 Module Alignment
Mechanism
When there is an expansion module below this
module, the alignment mechanism is extended to lock
into the lower module.
JANUARY 2023 35
SPECTRA STACK LIBRARY
USER GUIDE
CHAPTER 1 - PRODUCT OVERVIEW
