8B-74 Air Bag System:
DTC Troubleshooting
Step Action Yes No
1 1) With ignition switch OFF, disconnect side-air bag
(inflator) module connector under front seat cushion.
2) Check proper connection to driver or passenger side-air
bag (inflator) module at terminals in “L25” or “L30”
connector.
3) If OK, then connect special tools (B) and (C) to side-air
bag (inflator) module connector disconnected at the Step
1.
Special tool
(B): 09932–75010
(C): 09932–78340
4) Check SDM DTC.
With ignition switch ON, is DTC B1064 or B1068 still
indicated?
Go to Step 2. Go to Step 3.
“L25”, “L30”
(C)
(B)
STEERING WHEEL
I4RS0A820032-01
